1. Unique Structural Design: The current distribution is uniform, excellent electrical conductivity, low internal resistance of the battery, to avoid thermal runaway, to ensure the reliability and safety of the battery
2. High Energy Density Cell: High capacity, light weight, low self-discharge rate, can keep the battery power for a long time, the service life of the battery is more durable.
3. Deep Cycle: Charging and discharging cycle times of not less than 3000 times.
4. With gyroscope anti-theft function, charging current limit function, 48V DC output, directly adapted to most of the communication equipment.
5. Application Scenarios:
► Lithium-ion batteries for power storage
► 5G communication base station system
► Monitoring power system
► Centralized large server room power supply system
► Distributed small server room power supply system
► Instrumentation and automatic control system
► General uninterruptible power supply system
► Power supply system for electric tools
► Data center system
6.Parameter
|
Item Name |
48V Lithium Server Rack Battery |
||
|
Item Model |
SJ48100B |
||
|
Battery Type |
LiFePO4 |
||
|
Rated Power |
4800 Wh |
||
|
Product Size |
Length |
Width |
Height |
|
480mm |
450mm |
132mm |
|
|
Package Size |
Length |
Width |
Height |
|
480mm |
470mm |
172mm |
|
|
Weight |
Net Weight |
Gross Weight |
|
|
39.1±3% kg |
39.7±3% kg |
||
|
Shell Material |
ABS |
||
|
Life Cycle |
25 ℃,0.5 C,80%DOD,≥3000 cycles |
||
|
Self-discharge Rate |
25℃,≤3%/per month |
||
|
Standard Charge/Discharge Current |
50 A |
||
|
Standard Charging Voltage |
53.5 V |
||
|
Discharging Temperature |
-20℃ - 55℃ |
||
|
Charging Temperature |
-10℃ - 55℃ |
||
|
Protection Grade |
IP52 |
||
7. Advanced BMS: 48V Lithium Server Rack Battery utilize an advanced BMS that provides comprehensive overcharge, over-discharge, over-current, and short-circuit protection, as well as an extremely low self-discharge rate. It also features an important high temperature cut-off function that prevents charging temperatures from exceeding zero degrees Celsius.
8. Practical: Our 48V Lithium Server Rack Battery, crafted with a durable metal shell and a slim profile, efficiently saves space compared to series of 4*12V 100Ah batteries. It can be easily mounted in a 3U server rack, making it a practical choice for compact energy storage systems
|
Item Name |
48V Lithium Server Rack Battery |
|
Rated Voltage |
48V |
|
Rated Capacity |
100Ah |
